SoliBoard NXT-Grade

Vulcor is proud to introduce our SoliBoard NXT-grade, our first 1300°C rated low bio persistence (LBP) fiber based board. SoliBoard NXT-grade is manufactured from a our low bio persistence bulk fiber with selected inorganic and organic fillers to deliver high strength and performance in refractory linings. SoliBoard can be used for a wide range of application in refractory linings or condensing boilers.

We manufacture the SoliBoard product range on our continuous board line, with state of the art drying techniques. This drying process is much more sustainable, leading to 50 % energy saving compared to conventional drying techniques and allows us to dry the product to the core to a thickness of 100 mm. As it is manufactured on our continuous board line, which spans over 200 m (600 ft), our product are much more controlled and consistent compared to batch manufactured vacuum forming process boards. As a result we can offer you a uniform, lightweight, low shot and stable board at high consistency, quality and performance.

All products in the SoliWool ULS fibers product range, like the SoliBoard NXT, meet the requirements specified under NOTE Q of European Regulation 1272/2008. All SoliBoard NXT products are therefore exonerated from labelling requirements in Europe.

The SoliBoard NXT-grade is our boosted, low bio persistence, 1300°C rated general purpose board and engineered to perform in a wide range of applications up to 1150°C continuously. The SoliBoard standard product range consists of 3 types of standard refractory ceramic fiber (RCF) boards, and an extensive range of low bio persistence (LBP) boards. We also deliver a Special Grade Boards range for High Strength or, when based on PCW fiber, boards for the most demanding applications.

Description

​Benefits

  • Low shot technology
  • Excellent insulation performance
  • High handling strength
  • Resistant to erosion from high gas velocities
  • Can be used in direct flame contact
  • Low shrinkage
  • Excellent thermal stability
  • Resistant to thermal shock
  • Exonerated of carcinogenic classfication under Note Q

Typical applications

  • Thermal insulation for furnace linings
  • High temperature back-up insulation
  • Tundish and launder covers in the casting of various alloys
  • Lining combustion chamber for gas fired boilers and heaters
  • General technical insulation of furnaces and technical installations

Product range

SoliBoard is part of an extensive product range supplied by Vulcor Insulation. Vulcor Insulation is supplying insulation solutions from cryogenic to high temperature
applications. All products offered by Vulcor are manufactured in house or sourced from exclusive trusted partners.

Technical support

Vulcor Insulation provides specifiers and customers with guidance on all aspects of the materials selection for their application, the installation and compliance with relevant regulations and performance standards.

For additional information about product performance, or to identify the recommended product for your application, please contact the team at Vulcor Insulation.

Type

Boards from high temperature low bio persistence (LBP) fiber and selected fillers.

Temperature range

SoliBoard ULS-grade has a classification temperature of 1300°C.

The maximum continuous use temperature provided on the website is a guideline and only applicable in a clean oxidizing atmosphere.

First firing

All Board formulations contain a small amount of organic binder to improve the cold handling strength which burns out on first firing at approximately 200-300°C.

Availability

SoliBoard is available in the standard dimensions 1200×1000 mm or 1000×600 mm which are supplied on carton boxes of 120-150 mm high (based on the thickness of the board) and Please refer to the list below for packaging details of the SoliBoard product range other sizes are available on request.
