Description
SoliPaper ULS-grade is our standard Low Bio Persistence fiber paper product and is used in a wide range of applications with great success. SoliPaper ULS-grade has a classification temperature of 1260°C and is recommended for use till 1100°C continuously.
SoliPaper ULS is manufactured from true Generation III ultra clean and fine SoliWool fiber. SoliPaper ULS is very flexible, and offers a high tensile strength thanks to the high fiber index. As a result it is particulary suited to all applications requiring further processing (laminated composites, die-cutting, rolling, folding).
Utilizing an optimized production process we are able to create a product with a smooth surface, close dimension tolerances, exceptionally low dust, high handling strength, and an improved thermal insulating performance. SoliPaper ULS-grade is very flexible, and offers a high tensile strength as result of the high fiber index.
SoliPaper ULS is using organic binders which burn out on the first firing, starting at approximately 250°C.
All products in the SoliWool ULS fiber product range, like the SoliPaper ULS, meet the requirements specified under NOTE Q of European Regulation 1272/2008. All SoliPaper ULS products are therefore exonerated from labelling requirements in Europe.
Next to the SoliPaper in the low bio persistence grade (LBP) we also offer a standard range of RCF(-Zr) Papers from 1260 to 1430°C and special paper grades using PCW fibers up till 1600°C.
Benefits
- High fiber index
- Low shot technology
- Excellent insulation performance
- High handling strength
- Close dimensional tolerance
- Smooth surface and low dust
- Easy die-cutting for high temperature gaskets
- Excellent thermal stability
- Exonerated of carcinogenic classification under Note Q
Typical applications
- Filler for expansion joints between pre-casted shapes and IFB linings
- Gasket for domestic appliances
- Thermal insulation in automotive heat shields
- Non-ferrous molten metal handling
- General technical insulation of furnaces and technical installations
Type
Paper from Low Bio Persistence (LBP) high temperature insulation fiber.
Temperature range
SoliPaper ULS-grade has a classification temperature of 1260°C and advised for maximum continuous use at 1100°C.
The maximum continuous use temperature provided on the website is a guideline and only applicable in a clean oxidizing atmosphere.
Product range
SoliPaper is part of an extensive product range supplied by Vulcor Insulation. Vulcor Insulation is supplying insulation solutions from cryogenic to high temperature applications. All products offered by Vulcor are manufactured in house or sourced from exclusive trusted third party partners.
Technical support
Vulcor Insulation provides specifiers and customers with guidance on all aspects of the materials selection for their application, the installation and compliance with relevant regulations and performance standards.
For additional information about product performance, or to identify the recommended product for your application, please contact the team at Vulcor Insulation.
Availability
SoliPaper ULS-grade is manufactured in a density of 190 to 210 kg/m3 and in a standard thickness range from 1 till 10 mm. Our SoliPaper is standard available in both Jumborolls and standard rolls.
SoliPaper in standard rolls is supplied in carton boxes. All our paper are packed on a heat treated export pallet. Standard rolls are packed with 42 rolls rolls per pallet. Please refer to the list below for dimensions of the standard rolls, other sizes and thicknesses are available on request.
| Length (mm) | Width (mm) | Thickness (mm) |
|---|---|---|
| 60000 | 610 | 1 |
| 30000 | 610 | 2 |
| 20000 | 610 | 3 |
| 15000 | 610 | 4 |
| 12000 | 610 | 5 |
| 10000 | 610 | 6 |
| 8500 | 610 | 7 |
| 7500 | 610 | 8 |
| 6000 | 610 | 10 |
Next to the standard rolls we also supply our SoliPaper ULS-grade in Jumbo Rolls. Jumbo Rolls are ideal for large quantity die-cut gaskets which can be used in the automotive –and domestic appliances industry, minimizing cutting waste. The jumborolls have a standard width of 1200 mm which allow them to be loaded with 4 rolls per pallet. The jumborolls are provided with heist belts in the roll which allow swift loading on the feeder for high volume gasket cutting.
| Length (mm) | Width (mm) | Thickness (mm) |
|---|---|---|
| 180000 | 1200 | 2 |
| 120000 | 1200 | 3 |
| 90000 | 1200 | 4 |
| 72000 | 1200 | 5 |
| 60000 | 1200 | 6 |
| 45000 | 1200 | 8 |
| 36000 | 1200 | 10 |
Properties
| Properties measured | Standard | Unit | SoliPaper ULS-grade |
|---|---|---|---|
| Grade | LBP | ||
| Colour | white | ||
| Classification temperature | °C | 1260 | |
| Continuous use temperature | °C | 1100 | |
| Density | kg/m3 | 190-210 | |
| Loss on ignition | wgt% | 8 | |
| Tensile strength | |||
| Thickness 1 to 4 mm | kPa | > 400 | |
| Thickness 4 to 6 mm | kPa | > 650 | |
| Permanent linear shrinkage | EN 1094-7 | % | |
| @1200°C | < 2 | ||
| Thermal conductivity | ASTM C-201 | W/mK | |
| @200°C | 0,05 | ||
| @400°C | 0,07 | ||
| @600°C | 0,10 | ||
| @800°C | 0,13 | ||
| @1000°C | 0,19 | ||
| Chemical composition (after firing) | ISO12677 | % | |
| SiO2 | 63-66 | ||
| CaO | 26-33 | ||
| MgO | 3-7 | ||
| Other | < 0,8 |
