Description
SoliPaper ZR-grade is our highest positioned refractory ceramic fiber paper (RCF-Zr)1430 in the SoliPaper product range, only having the SoliPaper PCW to outperform on classification temperature. The high classification temperature is the result of the use of Zirconia in the chemical composition of the fiber. The SoliPaper ZR-grade has a classification temperature of 1430°C and is engineered to perform continuously in a wide range of applications up till 1300°C.
Utilizing an optimized production process to manufacture uniform, lightweight, low shot and flexible paper-like products, we are able to create a product with a smooth surface, close dimension tolerances, exceptionally low dust, high handling strength, better thermal insulating performance and retains its flexibility after compression. SoliPaper ZR-grade is very flexible, but offers a high tensile strength as result of the high fiber index. It is particulary suited to all applications requiring further processing (laminated composites, die-cutting, rolling, folding).
SoliPaper ZR-grade is part of the SoliPaper product range. Next to the SoliPaper from RCF(-Zr) fiber we also offer an extensive range of low bio persistence grade (LBP) papers and special paper grades using PCW fibers up till 1600°C.
Benefits
- High fiber index
- Low shot technology
- Excellent insulation performance
- High handling strength
- Close dimensional tolerance
- Smooth surface and low dust
- Easy die-cutting for high temperature gaskets
- Excellent thermal stability
Typical applications
- Filler for expansion joints between pre-casted shapes and IFB linings
- Gasket for domestic appliances
- Thermal insulation in automotive heat shields
- Non-ferrous molten metal handling
- General technical insulation of furnaces and technical installations
Type
Paper manufactured from Refractory Ceramic Fiber (RCF) high temperature insulation fiber.
Temperature range
SoliPaper ZR-grade has a classification temperature of 1430°C and advised for maximum continuous use at 1300°C.
The maximum continuous use temperature provided on the website is a guideline and only applicable in a clean oxidizing atmosphere.
Product range
SoliPaper is part of an extensive product range supplied by Vulcor Insulation. Vulcor Insulation is supplying insulation solutions from cryogenic to high temperature applications. All products offered by Vulcor are manufactured in house or sourced from exclusive trusted third party partners.
Technical support
Vulcor Insulation provides specifiers and customers with guidance on all aspects of the materials selection for their application, the installation and compliance with relevant regulations and performance standards.
For additional information about product performance, or to identify the recommended product for your application, please contact the team at Vulcor Insulation.
Availability
SoliPaper ZR-grade is manufactured in a density of 190 to 210 kg/m3 and in a standard thickness range from 1 to 10 mm. Our SoliPaper is standard available in both Jumborolls and standard rolls.
SoliPaper in standard rolls is supplied in carton boxes. Standard rolls are packed with 42 rolls per pallet. Please refer to the list below for dimensions of the standard rolls.
| Length (mm) | Width (mm) | Thickness (mm) |
|---|---|---|
| 60000 | 610 | 1 |
| 30000 | 610 | 2 |
| 20000 | 610 | 3 |
| 15000 | 610 | 4 |
| 12000 | 610 | 5 |
| 10000 | 610 | 6 |
| 8500 | 610 | 7 |
| 7500 | 610 | 8 |
| 6000 | 610 | 10 |
Next to the standard rolls we also supply our SoliPaper ZR-grade in Jumbo Rolls. Jumbo Rolls are ideal for large quantity die-cut gaskets which can be used in the automotive –and domestic appliances industry, minimizing cutting waste. The jumborolls have a standard width of 1220 mm which allow them to be shipped with 4 rolls per pallet. The jumborolls are provided with heist belts in the roll which allow swift loading on the feeder for high volume gasket cutting.
| Length (mm) | Width (mm) | Thickness (mm) |
|---|---|---|
| 180000 | 1200 | 2 |
| 120000 | 1200 | 3 |
| 90000 | 1200 | 4 |
| 72000 | 1200 | 5 |
| 60000 | 1200 | 6 |
| 45000 | 1200 | 8 |
| 36000 | 1200 | 10 |
Properties
| Properties measured | Standard | Unit | SoliPaper ZR-grade |
|---|---|---|---|
| Grade | RCF | ||
| Colour | white | ||
| Classification temperature | °C | 1430 | |
| Continuous use temperature | °C | 1300 | |
| Density | kg/m3 | 192-210 | |
| Loss on ignition | wgt% | < 7 | |
| Permanent linear shrinkage | EN 1094-7 | % | |
| @1400°C | < 3 | ||
| Thermal conductivity | ASTM C-201 | W/mK | |
| @200°C | 0,06 | ||
| @400°C | 0,08 | ||
| @600°C | 0,11 | ||
| @800°C | 0,16 | ||
| @1000°C | 0,22 | ||
| Chemical composition (after firing) | ISO12677 | % | |
| SiO2 | 48-51 | ||
| AI2O3 | 34-37 | ||
| ZrO2 | 14-17 | ||
| Fe2O3 | < 0,2 | ||
| Other | < 0,25 |
