Description
To differentiate our classic RCF-Zr blanket from the competition offering we ensure the high classification temperature by the chemical composition. This means we have a tight control on the zirconia contents of our blankets, and we benefit from the use of our ULS spinning technology.
As a result Soliblanket ZR-grade is stronger, feels more comfortable to handle and provides better thermal insulation. During installation the benefit of our advanced spinning process offers a higher resiliency after compression. This is particularly important when making fiber modules or in case the blanket (strip) is installed perpendicular to the main fiber orientation, or in easier words; stack(bonded).
SoliBlanket ZR-grade is part of the SoliBlanket product range. With a variety of four Refractory Ceramic Fiber (RCF) grades and the famous ‘ULS®’ Low Bio Persistence Fiber grade we are offering one of the most extensive ranges of high temperature fiber blankets in the market today. With our different chemical compositions we are able to provide a solution to nearly every atmosphere or temperature.
Benefits
- Proven technical solution
- Low shot technology
- Excellent insulation performance
- High handling strength
- Unaffected by most chemicals
- Excellent thermal stability
- Resistant to thermal shock
Typical applications
- Thermal insulation for lining stacks and chimneys
- Blanket for module making
- Furnace lining in Ceramics and Glass
- Thermal insulation for Petrochemical Industry
- Refractory lining for Steel Treatment
- General technical insulation of furnaces and technical installations.
Type
Blanket from high temperature Refractory Ceramic Fiber insulation wool.
Temperature range
SoliBlanket ZR-grade has a classification temperature of 1430°C.
The maximum continuous use temperature provided on the website is a guideline and only applicable in a clean oxidizing atmosphere.
Product range
SoliBlanket is part of an extensive product range supplied by Vulcor Insulation. Vulcor Insulation is supplying insulation solutions from cryogenic to high temperature applications. All products offered by Vulcor are manufactured in house or sourced from exclusive trusted third party partners.
Technical support
Vulcor Insulation provides specifiers and customers with guidance on all aspects of the materials selection for their application, the installation and compliance with relevant regulations and performance standards.
For additional information about product performance, or to identify the recommended product for your application, please contact the team at Vulcor Insulation.
Availability
All SoliBlanket products from the Standard Grade RCF range are available in densities from 64 to 160 kg/m3 and in a standard thickness range from 6 till 50 mm.
SoliBlanket is standard supplied in shrink wrap plastic film, and can be supplied in carton boxes (except 6 mm blanket which is only available with 4 rolls per carton box). The blankets in shrink wrap are placed on a heat treated export pallet with 24 rolls per pallet. Please refer to list below for availability of densities and dimensions.
| Length (mm) | Width (mm) | Thickness (mm) | 64 kg/m3 | 96 kg/m3 | 128 kg/m3 | 160 kg/m3 |
|---|---|---|---|---|---|---|
| 5500 | 610 | 6 | X | |||
| 14640 | 610 | 13 | O | X | X | X |
| 9760 | 610 | 19 | O | O | O | O |
| 7320 | 610 | 25 | X | X | X | X |
| 4880 | 610 | 38 | X | X | X | |
| 3660 | 610 | 50 | X | X | X | |
| Standard item | X | |||||
| On request | O |
Properties
| Properties measured | Standard | Unit | SoliBlanket | ZR-grade |
|---|---|---|---|---|
| Grade | RCF | |||
| Colour | white | |||
| Classification temperature | °C | 1430 | ||
| Continous use temperature | °C | 1300 | ||
| Density | kg/m3 | 96 | 128 | |
| Tensile strength | EN 1094-1 | kPa | 65 | 90 |
| Permanent linear shrinkage | EN 1094-1 | % | ||
| @1300°C | < 2 | |||
| @1400°C | < 3 | |||
| Thermal conductivity | ASTM C-201 | W/mK | ||
| @200°C | 0,05 | 0,05 | ||
| @4000°C | 0,09 | 0,08 | ||
| @600°C | 0,13 | 0,12 | ||
| @800°C | 0,20 | 0,18 | ||
| @1000°C | 0,28 | 0,25 | ||
| @1200°C | 0,32 | |||
| Chemical composition | ISO 12677 | % | ||
| SiO2 | 48 - 51 | |||
| AI2O3 | 34 - 37 | |||
| ZrO2 | 14 - 17 | |||
| Fe2O3 | < 0,2 | |||
| Other | < 0,25 |
